3.2.2 Bonding and Grounding
1. In addition to being properly grounded as
described below in Sec. 3.2.3, and in accordance
with the requirements of the National Electrical
Code (NEC), or in Canada the Canadian
Electrical Code (CEC), the pump motor must
be bonded to all metal parts of the swimming
pool, spa or hot tub structure and to all electrical
components and equipment associated with the
pool/spa water circulation system.
2. The bonding must be accomplished by using a
solid copper conductor, No. 8 AWG or larger.
In Canada No. 6 AWG or larger must be used.
Bond the motor using the external bonding lug
provided on the motor frame.
National Electrical Code® (NEC®) requires bonding
of the Pool Water. Where none of the bonded pool
equipment, structures, or parts are in direct connection
with the pool water; the pool water shall be in
direct contact with an approved corrosion-resistant
conductive surface that exposes not less than 5800
mm² (9 in²) of the surface area to the pool water at all
times. The conductive surface shall be located where
it is not exposed to physical damage or dislodgement
during usual pool activities, and it shall be bonded in
accordance with the bonding requirements of NEC
Article 680. Refer to locally enforced codes for any
additional bonding requirements.
RECOMMENDED MINIMUM WIRE SIZE FOR SHP PUMPS* (1-PHASE POWER)
Distance from Sub-Panel 0-50 Feet 50-100 Feet 100-150 Feet 150-200 Feet
Pump Model
Inverse - Time Circuit
Breaker or Branch
Fuse AMPs
Class: CC, G, H, J, K,
RK, or T
Voltage Voltage Voltage Voltage
208-
230VAC
115VAC 208-230VAC 115 VAC 208-230VAC 115 VAC 208-230VAC 115 VAC 208-230VAC 115 VAC
SHPF.50 / SHPM.75 15A 15A 14 12 12 8 10 6 8 6
SHPF.75 / SHPM1.0 15A 15A 14 12 12 8 10 6 8 6
SHPF1.0 / SHPM1.5 15A 20A 12 10 10 8 8 6 6 4
SHPF1.5 / SHPM2.0 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
SHPF2.0 / SHPM2.5 15A N/A 12 N/A 8 N/A 6 N/A 6 N/A
SHPF3.0 20A N/A 10 N/A 8 N/A 6 N/A 4 N/A
SHPF5.0 25A N/A 10 N/A 6 N/A 4 N/A 4 N/A
SHPF1.0-2 ** 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
SHPF1.5-2 ** 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
SHPF2.0-2 ** 15A N/A 12 N/A 8 N/A 6 N/A 6 N/A
SHPM1.5-2 ** 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
SHPM2.0-2 ** 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
SHPM2.5-2 ** 15A N/A 12 N/A 8 N/A 6 N/A 6 N/A
*Assumesthree(3)copperconductorsinaburiedconduitand3%maximumvoltagelossinbranchcircuit.AllNationalElectricalCode
®
(NEC
®
)andlocalcodesmustbe
followed. Table shows minimum wire size and branch fuse recommendations for a typical installation per NEC.
**Two-speed pumps are not rated for use with 208 VAC.
Table 2. Recommended Minimum Wire Size
RECOMMENDED MINIMUM WIRE SIZE FOR SHP PUMPS* (3-PHASE POWER)
Distance from Sub-Panel 0-50 Feet 50-100 Feet 100-150 Feet 150-200 Feet
Pump Model
Inverse - Time Circuit
Breaker or Branch
Fuse AMPs
Class: CC, G, H, J, K,
RK, or T
Voltage Voltage Voltage Voltage
460VAC 115VAC
460VAC 208-230VAC 460VAC 208-230VAC 460VAC 208-230VAC 460VAC 208-230VAC
SHPF1.0-3PH 15A 15A 14 12 12 12 10 10 8 8
SHPF1.5-3PH 15A 15A 12 12 10 10 8 8 6 6
SHPF2.0-3PH 15A 15A 12 12 10 10 8 8 6 6
SHPF3.0-3PH 15A 15A 12 12 8 8 6 6 6 6
SHPF5.0-3PH 15A 20A 10 10 6 6 4 4 4 4
*Assumesfour(4)copperconductorsinaburiedconduitand3%maximumvoltagelossinbranchcircuit.AllNationalElectricalCode
®
(NEC
®
)andlocalcodesmustbe
followed. Table shows minimum wire size and branch fuse recommendations for a typical installation per NEC.
Page 9
ENGLISH
Jandy
®
Stealth
™
Pumps
|
Operation Manual
