UMG 96RM-M

• 1p 2i (addr. 510 = 6)

I1 I2 I3

• 3p 3w (addr. 510 = 4)

• 1p 2w (addr. 510 = 7)

I1 I2 I3

• 2p 4w (addr. 510 = 5)

Fig. Measured values derived from the I3 current

measurement input are assumed to be zero and

not calculated.

Fig. Measured values derived from the I2 and I3

current measurement inputs are assumed to be

zero and not calculated.

Fig. System with uniform phase loading. The

measured values for the I2 current measurement

input are calculated.

Fig. System with uniform phase loading. The

measured values for the I2 and I3 current

measurement inputs are calculated.
