99
UMG 96RM-M
C
Only the first three positions (###) of a value are shown on the display. Values larger than
1,000 are marked with „k”. Example: 003k = 3000
750 SHORT RD - Software release
754 SERNR RD - Serial number
756 SERNR RD - Production number
800 FLOAT RD Hz Frequency
802 FLOAT RD - Voltage, positive sequence
804 FLOAT RD - Voltage, negative sequence
806 FLOAT RD - Voltage, zero sequence
808 FLOAT RD V Voltage L1-N
810 FLOAT RD V Voltage L2-N
812 FLOAT RD V Voltage L3-N
814 FLOAT RD V Voltage L1-L2
816 FLOAT RD V Voltage L2-L3
818 FLOAT RD V Voltage L1-L3
820 FLOAT RD - Fund. power factor, CosPhi; U L1-N IL1
822 FLOAT RD - Fund. power factor,, CosPhi; U L2-N IL2
824 FLOAT RD - Fund. power factor,, CosPhi; U L3-N IL3
826 FLOAT RD - Sum; CosPhi sum3=POsum3/Ssum3
828 FLOAT RD - Power factor; U L1-N IL1
830 FLOAT RD - Power factor; U L2-N IL2
832 FLOAT RD - Power factor; U L3-N IL3
834 FLOAT RD - Sum; Power factor sum3=Psum3/Ssum3
836 FLOAT RD % THD, U L1N, based on U0 L1
838 FLOAT RD % THD, U L2N, based on U0 L2
Addresse Format RD/WR Unit Note
Tabelle 2 - Adress list (frequently used measured values)
