Technical Specifications
Overview of measured values
Designation Measured Mean- Max- Min-
values values values values
Voltage
UL1-N, UL2-N, UL3-N x x x x
UL1-L2, UL2-L3, UL3-L1 x x x x
Current
IL1, IL2, IL3, IN x x x
Mean current values IL1, IL2, IL3, IN x
Phase position
CosPhiL1, CosPhiL2, CosPhiL3, CosPhiSum, x x x x
Power output
PL1, PL2, PL3, Psum, x x x
QL1, QL2, QL3, Qsum, x x x
SL1, SL2, SL3, Ssum, x x x
Mean output values PL1, PL2, PL1, Psum x
Frequency in L1 x x x x
Negative, positive, zero phase sequence sys. x x x x
Voltage symmetry x x x x
Phase sequence x x x x
K-factor L1, L2, L3, x x x x
Fourier analysis DFT(1, 3, 5, 7, 9, .. 15)
Voltage UL1-N, UL2-N, UL3-N x x x x
Current IL1, IL2, IL3, x x x x
THD
UL1-N, UL2-N, UL3-N x x x
IL1, IL2, IL3 x x x
Work
Active energy (without backstop) x
Active energy (drawn) x
Active energy (supply) x
Tarrifs 1 .. 4
Active energy(without backstop) x
Active energy (drawn) x
Active energy (supply) x
EMAX active power x x
EMAX trend value x
Inputs and outputs
Temperature measurement input x x x x
Temperature measurement, internal x x x x
Analog input (0/4 .. 20mA) x x x x
Analog outputs (0, 1) x
Digital outputs (1 .. 6) x
Digital inputs (1 .. 6) x
Active power, S0-inputs (1 .. 6) x
Meters (1 .. 6) x
