Inputs and outputs
Digital inputs and outputs
Overvoltage category : 32V CATI
Refreshment rate
inputs, outputs, flags : 50Hz 200ms; 60Hz 167ms
6 Digital inputs
Maximum counting frequency (S0) : 20Hz
Current input : approx 1mA .. 6mA
6 Digital outputs, positive switching (not short-circuit proof)
As switching output
Switching voltage : max. 28VDC
Switching current : max. 30mA
Switching frequency (50Hz system) : max. 2.5Hz
Switching frequency (60Hz system) : max. 3Hz
Auxiliary voltage, external : 20V .. 28VDC
As pulse output (S0)
Switching frequency : max. 20Hz
Switching current : max. 30mA
Max. cable length : 100m
Auxiliary voltage, external : 20V .. 28VDC
Analog inputs and outputs (options)
Overvoltage category : 32V CATI
Accuracy : +-1.5% vMb.
2 analog outputs : 0/4 .. 20mA
Burden : max. 300 Ohm
External auxiliary power : 20V .. 28V DC
Residual ripple : max. 2V, 50Hz
1 analog input „0 .. 20mA“ : 0 .. 20mA
1 analog input „PT100“ : PT100, PT1000, KTY83, KTY84
Interfaces (options)
Overvoltage category : 32V CATI
RS232 : 3-pin screw-plug in terminals.
Protocol : Modbus RTU
Transfer rate : 38.4kbps
RS485 (option) : Connector, SUB D 9-pin
Protocol, profibus (option) : Profibus DP/V0 to EN 50170
Transfer rate : 9.6kBaud up to 1.5MBaud
Protocoll, Modbus RTU : Modbus RTU/Slave, RTU/Master
Transfer rate : 9600bps, 19.2kbps, 38.4kbps, 115.2kbps
Ethernet 10/100Base-TX (option)
Connection : RJ-45
Functions : Modbus gateway, embedded webserver
Protocols : TCP/IP, EMAIL(SMTP), DHCP(BootP),
Modbus-TCP, Modbus over Ethernet,
Ping, NTP.
