5
The installation and startup instruc-
tions also describe options which are
not part of the scope of delivery.
Number Product No. Name
1 52 15 xxx
1)
UMG507 XX
2)
1 33 03 xxx
1)
Installation and startup instructions,
1 29 01 926 2 clips
1 51 00 104 CD with the following contents:
- „PSWbasic“ programming software.
- Supplementary device descriptions.
Product No. Name
0801504 Patch cable 3m, blue. (PC - switch/hub connection)
0801505 Patch cable 2m, twisted, grey, (PC - PC connection)
5210207 Connection cable, RS232, 2m, DSUB
2901903 Seal, 144x144
2101102 Battery, lithium CR2450N, 3V/540mAh
1)
Refer to delivery note for product number.
2)
Design options.
Incoming Inspection
UMG507 model options
Option L AD P EL E EP
1 RS232, Modbus RTU x x x x x x
1 RS485, Modbus RTU x x x x x x
1 RS485, Modbus RTU/Profibus DP V0 - - x - - x
1 Ethernet, 10baseT - - - x x x
1 Temperature input (e.g. PT100) - x x - x x
1 Analog input, 0 - 20mA - x x - x x
2 Analog outputs, 0/4 - 20mA - x x - x x
6 Digital inputs x x x - x x
6 Digital outputs x x x - x x
1 additional memory, 16MB (flash) - - - x x x
Model options available
Scope of delivery
Accessories available
All the delivered options and model
options are described on the delivery
note.
x = option available in this model
