Janome HD9 - Electronic Components Replacement; Electronic Component Locations; Connector Identification and Location

12
Printed circuit board F
LED
Printed circuit board A
Slide volume
Bobbin winder switch
Upper shaft sensor
Power transformer
Printed circuit board MS
Driving motor
Machine socket
Push - pull solenoid
Capacitor
Thread cutter switch
Bobbin winder motor
Replacing the Electronic Components
1. Location of the Electronic Components
2. Location of the Connectors
Motor sensor
Printed circuit board F
Thread cutter switch
Machine socket
(primary)
Power transformer
(primary)
Driving motor
Machine socket
(secondary)
Slide volume
Power transformer
(secondary)
Bobbin winder
switch
Push-pull
solenoid
Capacitor
Upper shaft sensor
LED
Program
