Janome HD9 - Circuit Board-F and Slide Volume

15
To remove:
Removed the top cover.
Pull out the printed circuit board F connector
q
,
slide volume connector
w
from the printed circuit
board A
e
.
Loosen the 3 setscrew (A). Remove the
ornamental panel
r
.
Remove the 3 setscrews (B) and remove the
printed circuit board F
t
from the panel.
Remove the 2 CS-rings
y
and slide volume
u
.
To attach:
Follow the above procedure in reverse.
(B)
(A)
(A)
5. Circuit Board-F and Slide Volume
