Janome JUNO E1030 - Function of LED, Buzzer and Lamp; Button Test; Bobbin Winder Switch; Presser Foot Lifter Switch

19
CORRECT CONDITION
SewinglampandLEDbacklightlit.LED
displays“1”.
PresstheMODEkey.
01)
FUNCTION OF
LED, BUZZER
AND LAMP
PROCEDURE
Turnonthepowerswitchwhile
simultaneouslypressingthe
auto-lockbuttonandneedleup/
down button.
Pressthe
MODEkeyto enterthe
self-diagnosticmode.
Iftheresultiscorrectcondition,
pressthe MODEkey toproceed
thenextstep.
Iftheresultisdefectivecondition,
pressthereversestitchbuttonto
proceedthenextstep.
DEFECTIVE CONDITION
Sewing lamp does not lit.
LEDbacklightdoesnotlit.
LEDdoesnotdisplay.
Buzzerdoesnotsound.
LEDdoesnotturnedon.
LEDdoesnotdisplayany
symbolsornotinorder.
–REMEDY–
ReplacethecircuitboardA.
ReplacethecircuitboardL.
Buzzersounds. LEDdisplays “8.8”as
shown
.
Threeindicatorlightsareon.
LEDdisplaysnothing.
Buzzersoundswhenbuttonispressed.
Buttonnumberisdisplayedwhenthe
followingbuttonsareispressed.
LEDdisplays“1”whenbutton
q
ispressed.
LEDdisplays“2”whenbutton
w
ispressed.
LEDdisplays“5”whenbutton
t
ispressed.
LEDdisplays“6”whenbutton
y
ispressed.
LEDdisplays“7”whenbutton
u
ispressed.
When
q
-
u
arepressed ,LEDdisplays
“b”asshown.
LEDdisplays“3”.
Whenthebobbinwinderspindleismoved
totheright,buzzersoundsandLED
displaysthe3Sasshown.
Pressbuttons1,2,5,6and7.
Iftheresultiscorrectcondition,
pressthe
MODEkey toproceed
thenextstep.
Iftheresultisdefectivecondition,
pressthereversestitchbuttonto
proceedthenextstep.
Movethebobbinwinderspindle
totheright.
Returnittotheleft.
Iftheresultiscorrectcondition,
pressthe
MODEkey to
proceedthenextstep.
Iftheresultisdefectivecondition,
pressthereversestitchbuttonto
proceedthenextstep.
02)
BUTTON
03)
BOBBIN
WINDER
SWITCH
SELF-DIAGNOSTIC TEST
STEP AND
ITEMS T
O
CHECK
Whenthebobbinwinderspindleismovedto
theleft,buzzersoundsandSdisappears.
LEDdisplays“4_”.
Theunderbarisdisplayedasshown.
Buzzerdoesnotsound.
LEDdoesnotdisplaythe
numbercorrectly.
–REMEDY–
ReplacethecircuitboardA.
Buzzerdoesnotsound.
Bobbinsymbolisnot
displayed.
–REMEDY–
Adjustthebobbinwinder
switchposition.
Replacethebobbinwinder
switch.
ReplacethecircuitboardA.
q
w
tyu
04)
PRESSER
FOOT
LIFTER
SWITCH
Notapplicableforthismodel.
PresstheMODEkeytoproceed
thenextstep.
