Jasic EVOLVE 200 - 1.4 Machine Components Identification

EVOLVE 200 USER MANUAL
8
7
4
1.4 Photos of the machine and instructions
Photos of the machine and instructions are as follows:
Code Name Description Refer to schematics
1 PCB MOTHER BOARD TJ010
2 PCB COMMUNICATION BOARD TJ003
3 PCB EMC BOARD TJ013
4 TRANSFORMER THE MAIN TRANSFORMER /
5 MOTOR WIRE FEEDER INTERNAL MIG
WIRE FEEDER
6
DEVICE POLARITY SWITCHING DEVICE
POLARITY CHANGE
7
PANEL FRONT PANEL
/
2
3
5
1
6
