EVOLVE 200 USER MANUAL
12
2.2 Welding operate mode instructions
Welding operate mode includes: 2T mode, 4T mode and SP mode. Welding operate mode is switched
by pushing the 2T/4T button, three kinds of Welding mode corresponding schematic diagrams as shown
below.
2.2.1 2T mode / 2T Spot mode
2.2.2 4T mode
4T 2T/4T (example)
