5. Alarms of the machine and troubleshooting
Table 5.1 Alarms of the machine and troubleshooting
ALARM
CODE
SHORT DESCRIPTION USER
DESCRIPTION
USER
ACTION 1
USER
ACTION 2
USER
CAUSE1
USER
CAUSE2
1 ALARM_VREFINT ANOMALY IN THE
CONTROL BOARD
POWER SUPPLY
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
2 ALARM_VBAT ANOMALY IN THE
CONTROL BOARD
POWER SUPPLY
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
BATTERY LOW FAULT
CONTROL
BOARD
3 ALARM_CPU_TEMPERA
TURE
HIGH
THEMPERATURE
OF THE CPU
POWER OFF and
wait a few minutes
for cooling
CONTACT THE
SERVICE
CENTER
HIGH AMBIENT
TEMPERATURE
CONTROL
BOARD FAULT
10 ALARM_BUS_I2C ANOMALY IN THE
CONTROL BOARD
COMUNICATION
INTERFACE
POWER OFF /
POWER ON
WAIT A COUPLE
OF MINUTES
CONTROL BOARD
FAULT
BAD
ELECTRICAL
CONNECTION
12 ALARM_MONITOR_5V ANOMALY IN THE
CONTROL BOARD
POWER SUPPLY
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
CLOUD
CONNECTION
BOARD FAULT
13 ALARM_MONITOR_MINU
S_15V
ANOMALY IN THE
CONTROL BOARD
POWER SUPPLY
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
14 ALARM_MONITOR_15V ANOMALY IN THE
CONTROL BOARD
POWER SUPPLY
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
15 ALARM_HALL_I2 ANOMALY IN THE
HALL SENSOR
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
BAD ELECTRICAL
CONNECTION
CONTROL
BOARD FAULT
HALL SENSOR
FAULT
16 ALARM_TABLE_MEMOR
Y
MEMORY DATA
ERROR
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
BAD ELECTRICAL
CONNECTION
CONTROL
BOARD FAULT,
MEMORY DATA
BOARD FAULT
20 V_PROBE_ALARM OUTPUT
VOLTAGE ERROR
AT THE START
UP MACHINE
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
21 ALARM_NO_FUNCTION NO SYNERGIC
PROGRAM
AVAILABLE
CHANGE
SYNERGIC
PROGRAM
CONTACT THE
SERVICE
CENTER
NO ABILITATIONS SOFTWARE
BUG
23 ALARM_ADC CONTROL BOARD
INTERNALL
ERROR
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
CONTROL BOARD
FAULT
30 TORCH_IN_SC ANOMALY IN THE
OUTPUT
VOLTAGE
CHECK THE
TORCH DO NOT
TOUCH THE
WORKING DESK
CONTACT THE
SERVICE
CENTER
SHORT CIRCUIT
OF THE TORCH
WITH THE
NEGATIVE
OUTPUT
CONTROL
BOARD FAULT
40 ALARM_NTC1_OPEN ANOMALY IN THE
THEMPERATURE
SENSOR
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
NTC DISCONNECT
OR FAULT
CONTROL
BOARD FAULT
42 ALARM_NTC1_IN_SHOR
T_CIRCUIT
OVER
TEMPERATURE
ERROR IN THE
POWER
INVERTER
WAIT COOLING A
FEW OF MINUTES
CONTACT THE
SERVICE
CENTER
FAULT COOLING
SYSTEM
TEMPERATUR
E ERROR IN
THE OUTPUT
SIDE OF THE
POWER
INVERTER
44 ALARM_TEMPERATURE
INVERTER
OVER
TEMPERATURE
IN THE INPUT
SIDE OF THE
POWER
INVERTER
WAIT COOLING A
FEW OF MINUTES
CONTACT THE
SERVICE
CENTER
FAULT COOLING
SYSTEM
OVER
TEMPERATUR
E IN THE INPUT
SIDE OF THE
POWER
INVERTER
51 ALARM_POWER_LOW POWER SUPPLY
NETWORK TOO
LOW
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
WRONG POWER
SUPPLY
NETWORK
CONTROL
BOARD FAULT
52 ALARM_POWER_HIGH POWER SUPPLY
NETWORK TOO
HIGHT
POWER OFF /
POWER ON
CONTACT THE
SERVICE
CENTER
WRONG POWER
SUPPLY
NETWORK
CONTROL
BOARD FAULT
