1.5 Main parameters of the welding machine
Model MIG200P(N2D1)
Input
Input power
AC230V single-phase 50/60Hz
Rated input capacity
5.83KVA
Power factor
0.65
Rated efficiency
82%
Rated no-load voltage 77V
Rated maximum output
MMA 180A/27.2V
Lift TIG 200A/18V
MIG 200A/24V
Rated duty 2T/4T 25%@AC230V Single-phase
Welding current
MMA 20A/20.8V
～
180A/27.2V
Lift TIG 5A/10.2V
～
200A/18V
MIG/pulsed MIG 20A/16V
～
200A/24V
Ambient
Operation temperature
-10
～
+40
℃
Storage temperature
-25
～
+55
℃
Protection class IP23S
Insulation class H
Cooling method Air cooling
Dimension of bare welding source 605mm*400mm*230mm
Dimension of packaged welding source
730
mm*
585
mm*
330*mm
Weight of bare welding source 17.0kg
Weight of complete welding source
19.0kg
