jcb Dumpster HTD5 User Manual

Section E - Hydraulics
Valves
Control Valve
E-32 E-32
9803-9570-4
Control Valve Block
Fig 4.
A1
A1
B1
B1
A2
A2
B2
B2
A3
A3
B3
B3
A5
A5
B5
B5
B6
B6
A6
A6
LIFT
LIFT
TRACK LH
TRACK LH
TRACK RH
TRACK RH
2nd SPEED
2nd SPEED
TIP
TIP
P1
P1
T2
T2
1
1
2
2
3
3
4
4
5
5
6
6
C
C
1 Inlet Section
2 Tip Section
3 2nd Speed Section
4 Right Track Section
5 Lift Section
6 Left Track Section
Torque Settings Nm Lbf ft
Section Tie Rod Nuts (C) 25 18.4
