DBV® Series
DBV-400 Banknote Validator
Section 1
This section provides a general overview of the
DBV
®
Series DBV-400 Banknote Validator Unit,
pictured in Figure 1-1. This section is designed to
help the user navigate through this guide with ease.
It includes the following information:
• DBV-400 Unit (SU and SD Models)
• Product Descriptions
• Precautions
• Primary Features
• Component Names
• Specifications
• Unit Dimensions
• Technical Contact Information
In order to make operating this device and navigat-
ing within this manual easier, the following illus-
trations are used:
• Safety Instructions need to be observed in order to
protect the operators and the equipment; these are
identified with Bold text and the following
pictographs:
• Special Notes affect the use of the Banknote
Validator; these are identified with italic text and
the following pictograph:
• Steps require the operator to perform specific
actions; these are identified with sequential
numbers (1, 2, 3, etc.).
DBV-400 Unit (SU and SD Models)
Figure 1-1 DBV-400 Unit
Figure 1-1 DBV-400 Unit
