JCM DBV-400 SD - Main Unit Parts List 2; Table 7-3 DBV-400 Main Unit Parts List 2

P/N 960-000180R_Rev. 1 {EDP #233427}_Feb. 12, 2020 © 2020, JAPAN CASH MACHINE CO., LTD.
7-6
Section 7 DBV™ Series DBV-400 Banknote Validator Exploded Views and Parts Lists
DBV-400 Main Unit Parts List 2
Table 7-3 DBV-400 Main Unit Parts List 2
Ref No. EDP No. Description QTY Remark
200 244550
Main Frame
1
201 234088 SUS PIN 3-66.8 1
202 234087 SUS PIN 3-25 1
203 234054 Hex Head P-Shaft 5
204 234021 Centering Gear 0.8-Z22 1
205 234020 Gear 0.8-Z20 3
206 234024 Transport Gear 0.8-Z22 1
207 239927 Transport Roller Gear A 1
208 234085 Drive Roller Gear 28-2 2
209
234057 Guide Chip D4-66A 1
234055 Guide Chip D4-72A 1
210
234058 Guide Chip D4-66B 1
234056 Guide Chip D4-72B 1
211 144840
2.6x8 Phillips, Self-Tapping, Binding Head Screw (Black)
*
*. P-TITE is recommended.
4
212 234113- Validation GuideDBV-400 Outside Guide Unit 1
Validation Guide
