7-12

Section 7 DBV™ Series DBV-400 Banknote Validator Exploded Views and Parts Lists

534 239497 Wave Shaped Spring Pin, Light Load 2

535

234069 Box Door D4-300 1

For DBV-400 Small Cash Box

244547 Box Door D4-500 1

For DBV-400 Medium Cash Box

244548 Box Door D4-1K 1

For DBV-400 Large Cash Box

536

238462 Box Receive Plate D4 1

For DBV-400 Small and Medium

Cash Box

234077 Box Receive Plate D4-1K 1

For DBV-400 Large Cash Box

537

238199 Box Spring D4-300 1

For DBV-400 Small Cash Box

238200 Box Spring D4-500 1

For DBV-400 Medium Cash Box

231386 Box 1500 Spring 2

For DBV-400 Large Cash Box

538

239112 Box Frame D4-300 1

For DBV-400 Small Cash Box

239115 Box Frame D4-500 1

For DBV-400 Medium Cash Box

239116 Box Frame D4-1K 1

For DBV-400 Large Cash Box

539 234043 Pusher Hinge Plate 1

540 234034 Serial Number Label 1

541 238461 Instruction Label 1

542 269569

Center Arm Shaft 1

*. P-TITE is recommended.

Table 7-6 DBV-400 Cash Box Parts List (Continued)

Ref No. EDP No. Description QTY Remark

February 12, 2020
