308 STARTING AND OPERATING
• When the LaneSense system senses a lane drift situation,
the left thick lane line and the left thin line turn solid white.
The LaneSense telltale changes from solid green to solid
yellow. At this time torque is applied to the steering wheel
in the opposite direction of the lane boundary.
For example: if approaching the left side of the lane the
steering wheel will turn to the right.
Lane Sensed With Solid White Thick Line, Solid White
Thin Line/Solid Yellow Telltale
• When the LaneSense system senses the lane has been
approached and is in a lane departure situation, the left
thick lane line flashes from white to gray, the left thin line
remains solid white and the LaneSense telltale changes
from solid yellow to flashing yellow. At this time torque is
applied to the steering wheel in the opposite direction of
the lane boundary.
For example: if approaching the left side of the lane the
steering wheel will turn to the right.
Lane Approached With Flashing White To Gray Thick
Line, Solid White Thin Line/Flashing Yellow Telltale
