Page 48 of 97
4– USE OF THE MACHINE IN
REGULAR WORKING CONDITIONS
______________________________________________________________________________________________
4 USE OF THE MACHINE IN REGULAR WORKING CONDITIONS
4.1 Machine starting
Battery version C+:
• Turn the battery switch on the ON position
• Take the switchboard
• Start the machine by turning the key switch of the switchboard on the ON position and push
turn on engine button to start-up the machine.If there ‘s not communication between machine and
switchboard on the display will appear message “ no communication CAN H – CAN L : in this case
check fuse and switch board- head connection.
Engine version CDH:
• Turn the battery switch on the ON position
• Take the switchboard
• Start the machine by turning the key switch of the switchboard on the ON position and push
turn on engine button to start-up the machine.
• Press the proper push button on the switchboard or turn the key switch on the RADIO position
and start the engine by means of the proper switch on the radio remote control.
4.2 Handling and stabilization of the machine
o Start the machine (see 4.1)
o The machine is equipped with a 2-way solenoid valve automatically making the oil flow to
the truck or crane system depending on what signal light is lit on the switchboard. In case
the 2-way solenoid valve didn’t work, deviate the oil manually as described in paragraph
4.7.
Drive the machine using the joysticks on the switchboard (press the push button on top of
every joystick and in the meanwhile move it to operate the tracks). To move the machine front
and back using only the right joystick, put down the swich 3B (see 3.1). Don’t turn quickly or
sheer when you are driving on a slope, risk of tipping over!!
CAUTION!!!
Safety transition driving position is only behind the machine
Min.
1m / 3,28 ft
