JEKKO SPD265C+ User Manual

Page 7 of 97
1-PREFACE
______________________________________________________________________________________________
1.2 Technical Specifications
Model SPD 265C+ Model SPD 266C+
Loading momentum
2600 Kgm 18720 lbsft
Loading momentum
2600 Kgm 18720 lbsft
Maximum working
height
7 m 22.9 ft
Maximum working
height
7 m 22.9 ft
Maximum SWL
1200 kg 2645 lbs
Maximum SWL
1200 kg 2645 lbs
Rotation
220°
Rotation
220°
Dimensions
2500x800x1750 mm
8.2x2.6x5.7 ft
Dimensions
2500x800x1750 mm
8.2x2.6x5.7 ft
Weight
1.700 Kg 3748 lbs
Weight
1.800 Kg 3748 lbs
Max outriggers load
1400 Kg 3086 lbs
Max outriggers load
1425 Kg 3086 lbs
Track area
Max track loadings
Max Slope Gradient
1080x230x2 mm
3.5x0.75x2 ft
0.34 Kg/cm
2
20°
Track area
Max track loadings
Max Slope Gradient
1080x230x2 mm
3.5x0.75x2 ft
0.35 Kg/cm
2
20°
ENGINE
Electric 24V-DC 3kW
(4 batteries 6V-240Ah)
ENGINE
Electric 24V-DC 3kW
(4 batteries 6V-240Ah)
Model SPD 360C+ Model SPD 360CDH
Loading momentum
4300 Kgm 30960 lbsft
Loading momentum
4300 Kgm 30960 lbsft
Maximum working
height
9.7 m 31,8 ft
Maximum working
height
9.7 m 31,8 ft
Maximum SWL
1800 kg 3968 lbs
Maximum SWL
1800 kg 3968 lbs
Rotation
360°
Rotation
360°
Dimensions
3100x800x1750 mm
10.2x6x5.7 ft
Dimensions
3100x800x1750 mm
10.2x6x5.7 ft
Weight
2200 Kg 4850 lbs
Weight
2200 Kg 4850 lbs
Max outriggers load
1900 Kg 4188 lbs
Max outriggers load
1900 Kg 4188 lbs
Track area
Max track loadings
Max Slope Gradient
1080x230x2 mm
3.5x0.75x2 ft
0.44 Kg/cm
2
20°
Track area
Max track loadings
Max Slope Gradient
1080x230x2 mm
3.5x0.75x2 ft
0.44 Kg/cm
2
20°
ENGINE
Electric 24V-DC 3kW
(4 batteries 6V-420Ah)
ENGINE
Diesel liquid cooled
14.9/20 kW/hp EPA
TIER4 12V (tank 6 Liter)
