Page 67 of 97
8 – TROUBLESHOOTING
______________________________________________________________________________________________
77 block for instability of SPD500 → Activate allowed function by the machine
78 block for wrong stabilization → Restore the correct stabilisation of the machine
79 block of jib SPD500 → You are not on a correct jib lifting area, see
lifting diagram!
80 clockwise slewing block SPD500 → Turn to counterclockwise direction
81 counterclockwise slewing block SPD500 → Turn to clockwise direction
83 clockwise slewing block SPD500 with
rotation sensor
→ Turn to counterclockwise direction
84 counterclockwise slewing block SPD500
with rotation sensor
→ Turn to clockwise direction
85 block due to error rotation sensor → Check and/or replace for probable failure
86 block due to forbidden working sector → Restore the correct stabilisation of the machine
87 block due to reading error rotation sensor → Do again setting of the sensor
88 slowing down because of forbidden
working sector
→ Normal safety movement
89 slowing down for minimum angle → Normal safety movement
90 engine off → Turn on the engine
91 machine start-up → Push turn on engine button to start-up machine
92 outriggers exclusion key → Turn outrigger exclusion key
93 reserve tank → Refill it
94 diesel engine water hight temperature → Stop immediately the motor
100 block due to max pressure hydraulic jib → Activate allowed function by the machine
101 block due to min pressure hydraulic jib → Lift the jib boom
102 slowing down because of max angle
main-hydraulic jib
→ Normal safety movement
103 block due to max angle main-hydraulic
jib
→ Activate allowed function by the machine
104 slowing down because of min angle
main-hydraulic jib
→ Normal safety movement
105 block due to max angle hydraulic jib → Activate allowed function by the machine
106 slowing down of main because of max
angle main-hydraulic jib
→ Normal safety movement
107 slowing down because of max
angle main-hydraulic jib with rope
→ Normal safety movement
108 block due to max angle main-hydraulic
jib with rope
→ Activate allowed function by the machine
109 slowing down because of min
angle hydraulic jib with rope
→ Normal safety movement
110 block due to min angle hydraulic jib with
rope
→ Activate allowed function by the machine
111 slowing down of main because of min
angle hydraulic jib with rope
→ Normal safety movement
112 block of main due to min
angle hydraulic jib with rope
→ Activate allowed function by the machine
113 spd360 hydraulic jib tool wrong selection → Select tool n° 2 ( use with hook) or 6 ( use with
rope)
