12 – TOOLS
______________________________________________________________________________________________
Installation:
¾ Connect the quick coupling to the proper housings and the battery recharging cable of the
machine by using the proper plug.
¾ Put the three-phase feeding plug (380V red) into the kit proper socket
Use:
¾ Turn the feeding key switch located on the switchboard on position 380V (3.1)
¾ Start the engine by means of the special black push button and turn the key switch on
position 1 or 2 – leave the key switch in the position that implies the engine correct rotation
(clockwise rotation as indicated by the arrow). In the diesel version, when the engine starts,
the light ON on the panel located behind the kit lights up to indicate that the machine battery
is recharging. The light marked with the lightning symbol indicates the presence of voltage.
Check at all times that the engine rotation is counterclockwise as
indicated by the arrow on the engine carter
¾ To stop the engine, press the red emergency mushroom push button or turn the key
switch on the 0 position
In case the engine doesn’t start:
- check that the emergency push button is deactivated (to unlock
it, turn the ring nut)
