3.8.3 System sound
System sounds are sounds or audio
files that the transmitter plays
when a system event is reached.
Any sound or audio file from the
transmitter's memory ("Audio"
folder) can be assigned to each
function.
Note: if there are three dots in the "File" column of the function line,
there is no sound associated with this event.
Low signal: A1/2: the assigned audio will be played when the signal
on the 2.4GHz band antennas is not stronger than the value
shown in the "Value" column. The recommended value is 1 (range
is 0 - 3).
Note: do not enter an unnecessarily high value for this parameter.
Even if you enter a value of 0, you still have enough "range" to return
the model when the "Low Signal" function is activated.
Telemetry loss: warning of loss of telemetry transmission (signal
from receiver to transmitter).
Note: this message only alerts you to signal loss with telemetry
data from the model to the transmitter. It does not mean loss of
control over the model because the signal level from the
transmitter to the model is "stronger".
Switched to backup: this function will be activated if a receiver for
the 900MHz band is installed in the model and the connection in
the 2.4GHz band is lost. The Duplex system will immediately
switch to the 900MHz backup system and notify you of this event.
Receiver reboot: information about resetting the receiver due to
low supply voltage. If the function is activated immediately after
switching on the model, it is not a defect. If the receiver resets
while the model is running, this is a dangerous condition and it is
wise to find out the cause (risk of crash).
Note: the entire time the "Range test" function is active, the
Duplex system is in the range test mode, so it has reduced power
and range.
