3.3- Technical specifications
Model: JF 2D Mill Machine
Drive Electric motor
Power of the motor 2 to 3 hp (1,5 to 2,5 kW)
Work speed 4.000 to 5.000 RPM
Cutting knives 2 units
Grinder hammers 16 units
Driving belt A46
Pulley* diameter which follow the machine:
- To 60 Hz motor (03.100100) 105 mm (2 groves)
- To 50 Hz motor (03.100198) 138 mm (2 groves)
* Only a pulley for motor accompanies the machine (50 or 60 Hz) set at the time of purchase of
the machine.
Impeller pulley diameter 90 mm
Approximated weight 68 Kg
Note: The motor, depending on the power, can weight up 32 Kg.
Dimensions (see picture below)
A (height) 1.337 mm
C (lenght) 654 mm
L (width) 648 mm
Front view
RH side
L
A
C
