JF 2D - Machine Presentation; Parts Identification

8
3- Machine presentation
3.1- Parts identification
1- Grain chopper
2- Feeding nozzle
3- Protection screen
4- Upper product output
5- Deflector
6- Counteknife
7- Inferior product outlet (desintegrated
grains)
8- Driving electric motors (Refer to page 10
about power requirements)
9- On-Off control (machine equipped with
original electric motor only)
10- Forage chopper knifes (2 units)
11- Grinder hammers (6 units)
12- Machine base
