JF 2D - Operation Adjustments; Grain Chopper Operation

16
5- Operation adjustments
5.1- To operate the JF 2D as grain chopper
a) Loosen latch (1) and rising cover (2).
b) Remove the countercover (3).
c) Select one of the sieves (4, 5, 6 or 7), according
desired product chips size and install it under the
impeller according picture aside.
NOTE.: See dimensions and application of sieves on
table on the next page.
d) Replace the countercover (3).
e) Close cover (2), rising and tighten latch (1).
Always use protective equipment to
adjust the machine, and do not forget to
do the operation with the machine off.
4
3
12
7
6
5
4
2
1
Sieves kit that come along with the machine
(see sieve chart on the next page).
