John Bean QUADRIGA 1000 - Page 110

110
Trouble shooting
Operator’s Manual QUADRIGA 1000/BB
“Error 212”
“Rotat. WrongDir”
“Error 213”
“SizeSensor Err“
“Error 220”
“UppBBPot Error“
“Error 221”
“LowBBPot Error“
“Error 222”
“VertPot Error“
“Error 223”
“HorizPot Error“
“Error 224”
“LiftPot Error“
“Error 225”
“RotatPot Error“
“Error 226”
“SizePot Error“
“Error 302”
“UpSwitch Engaged”
“Error 303”
“LoSwitch Engaged”
“Error 212”
“Rotat. WrongDir”
“Front Lifter Wrong Direction”
This error may be displayed during wheel loading/
unloading procedures if the Front Lifter moves in the
opposite direction to the required one; (Call the Technical
Assistance Service).
“Error 213”
“SizeSensor Err“
“Wheel Sensor not in home position”
At the end of the loading of wheel, this error is shown if
the size sensor is not in the calibration (home) position.
“Error 220”
“UppBBPot Error“
“Upper Bead Breaker potentiometer error”
(Call the Technical Assistance Service).
“Error 221”
“LowBBPot Error“
“Lower Bead Breaker potentiometer error”
(Call the Technical Assistance Service).
“Error 222”
“VertPot Error“
“Vertical Axis potentiometer error”
(Call the Technical Assistance Service).
“Error 223”
“HorizPot Error“
“Center post potentiometer error”
(Call the Technical Assistance Service).
“Error 224”
“LiftPot Error“
“Lift arm potentiometer error”
(Call the Technical Assistance Service).
“Error 225”
“RotatPot Error“
“Rotation arm potentiometer error”
(Call the Technical Assistance Service).
“Error 226”
“SizePot Error“
“Size sensor potentiometer error”
(Call the Technical Assistance Service).
“Error 302”
“UpSwitch Engaged”
“Upper Switch Active”
This error may be displayed during the automatic upper
bead breaking phase, if the switch on the arm appears
to be activated right from when the automated part starts
operating.
“Error 303”
“LoSwitch Engaged”
“Lower Switch Active”
This error may be displayed during the automatic lower
bead breaking phase, if the switch on the arm appears
to be activated right from when the automated part starts
operating.
