Johnson Controls DSH024C Series - FIGURE 4 - Single Compressor Unit - Typical Installation Configuration

13
SECTION 1 – INSTALLATION
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
1
LD27695
FIGURE 4 - SINGLE COMPRESSOR UNIT – TYPICAL INSTALLATION CONFIGURATION
Horizontal
Ductable Ceiling Air Conditioner Packaged Installation
Horizontal
Ductable Ceiling Air Conditioner Split Installation
Condenser
Section
Top Joining Strip
Evaporator Section
Side Cross-Member Angle
Ceiling
Exhaust
Outdoor
Air Intake
Condenser Section
Evaporator Section
Supply
Return
