Johnson Controls DSH024C Series - Motor and Pulley Data; TABLE 19 - Evaporator - Standard Blower Motor and Drive Data; TABLE 20 - Evaporator - Oversized Blower Motor and Drive Data

32
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
SECTION 1 – INSTALLATION
MOTOR AND PULLEY DATA
TABLE 19 - EVAPORATOR – STANDARD BLOWER MOTOR AND DRIVE DATA
MODEL
DRIVE
RANGE
(RPM)
MOTOR
ADJUSTABLE MOTOR
PULLEY
FIXED BLOWER PULLEY BELTS
HP
FRAME
SIZE
EFFICIENCY
(%)
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
RATING/
SIZE
DSH024C
416–
615
0.5 56 62 2.0–3.0 1VP34X5/8 8.7 AK89H A48
DSH036C
541–
798
0.75 56 68 2.0–3.0 1VP34X5/8 6.7 AK69H A45
DSH048C
505–
743
0.75 56 68 2.0–3.0 1VP34X5/8 7.2 AK74H A48
DSH060C
552–
814
1.0 145 88.5 2.0–3.0 1VP34X7/8 6.7 AK69H A48
DSH096C
565–
847
1.5 145 88.5 1.9–2.9 1VP34X7/8 6.2 AK64H A60
DSH120C
518–
686
3.0 184 88.5 2.8–3.8
1VP44X1
1/8
10.2 AK104H A68
TABLE 20 - EVAPORATOR – OVERSIZED BLOWER MOTOR AND DRIVE DATA
MODEL
DRIVE
RANGE
(RPM)
MOTOR
ADJUSTABLE MOTOR
PULLEY
FIXED BLOWER
PULLEY
BELTS
HP
FRAME
SIZE
EFFICIENCY
(%)
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
RATING/
SIZE
DSH024C
614–
906
0.5 56 62 2.0–3.0 1VP34X5/8 5.9 AK61H A43
DSH036C
739–
1091
0.75 56 68 2.0–3.0 1VP34X5/8 4.9 AK51H A42
DSH048C
697–
1028
1.0 145 88.5 2.0–3.0 1VP34X7/8 5.2 AK54H A46
DSH060C
784–
1158
1.5 145 88.5 2.0–3.0 1VP34X7/8 4.7 AK49H A45
DSH096C
734–
1016
2.0 145 88.5 2.4–3.4 1VP40X7/8 6.2 AK64H A61
DSH120C
640–
854
3.0 184 88.5 2.8–3.8 1VP44X1 1/8 8.2 AK84H A65
