Johnson Controls DSH024C Series - TABLE 21 - Condenser - Standard Blower Motor and Drive Data; TABLE 22 - Condenser - Oversized Blower Motor and Drive Data

33
SECTION 1 – INSTALLATION
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
1
TABLE 21 - CONDENSER – STANDARD BLOWER MOTOR AND DRIVE DATA
MODEL
DRIVE
RANGE
(RPM)
MOTOR
ADJUSTABLE MOTOR
PULLEY
FIXED BLOWER PULLEY BELTS
HP
FRAME
SIZE
EFFICIENCY
(%)
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
RATING/
SIZE
DSH024C
442–
652
0.5 56 62 2.0–3.0 1VP34X5/8 8.2 AK84H AX51
DSH036C
503–
743
0.75 56 68 2.0–3.0 1VP34X5/8 7.2 AK74H AX49
DSH048C
470–
694
1.5 145 88.5 2.0–3.0 1VP34X7/8 7.7 AK79H AX54
DSH060C
525–
775
1.5 145 88.5 2.0–3.0 1VP34X7/8 6.9 AK71H AX52
DSH096C
515–
686
3.0 184 88.5 2.8–3.8
1VP44X1
1/8
10.2 AK104H AX54
DSH120C
640–
854
3.0 184 88.5 2.8–3.8
1VP44X1
1/8
8.2 AK84H AX57
TABLE 22 - CONDENSER – OVERSIZED BLOWER MOTOR AND DRIVE DATA
MODEL
DRIVE
RANGE
(RPM)
MOTOR
ADJUSTABLE MOTOR
PULLEY
FIXED BLOWER PULLEY BELTS
HP
FRAME
SIZE
EFFICIENCY
(%)
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
PITCH
DIAMETER
(INCHES)
BROWNING
PART
NUMBER
RATING/
SIZE
DSH024C
614–
906
0.5 56 62 2.0–3.0 1VP34X5/8 5.9 AK61H A47
DSH036C
614–
906
0.75 56 68 2.0–3.0 1VP34X5/8 5.9 AK61H A47
DSH048C
639–
938
1.5 145 88.5 2.0–3.0 1VP34X7/8 5.7 AK59H AX50
DSH060C
636–
938
1.5 145 88.5 2.0–3.0 1VP34X7/8 5.7 AK59H AX50
DSH096C
603–
805
3.0 184 88.5 2.8–3.8
1VP44X1
1/8
8.7 AK89H AX52
DSH120C
837–
1027
5.0 184 88.5 4.4–5.4
1VP56X1
1/8
9.2 BK95H B60
