FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
SECTION 1 – INSTALLATION
TABLE 13 - DSH060C – SUPPLY AIR BLOWER PERFORMANCE
SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
1
0.0 0.1 0.2 0.3 0.4 0.6 0.8 1.0 1.2 1.4
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Low Static Drive
3
Factory Drive +1.0 HP Hi-Static Drive + 1.5 HP
1600 511 0.25 562 0.30 612 0.34 658 0.38 703 0.43 786 0.50 863 0.59 935 0.68 1002 0.78 1066 0.86 1800 575 0.36 620 0.41 666 0.45 708 0.50 749 0.55 826 0.64 898 0.74 967 0.84 1031 0.94 1092 1.04 2000 637 0.50 680 0.55 720 0.60 759 0.65 797 0.70 869 0.80 937 0.91 1001 1.01 1063 1.13 1121 1.24 2200 699 0.66 739 0.71 776 0.78 813 0.83 847 0.89 914 1.00 978 1.11 1039 1.23 1098 1.34 - - 2400 765 0.86 800 0.93 835 0.99 868 1.04 901 1.10 964 1.23 1024 1.35 1082 1.48 - - - -
NOTES: 1. Blower performance includes evaporator coil and 2-inch lters. 2. At higher evaporator airows and wet bulb conditions, condensate carry-over may occur. Decrease airow downward as necessary. 3. Field supplied low static drive. TABLE 14 - DSH060C – CONDENSER FAN PERFORMANCE
OUTDOOR
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
0.0 0.2 0.4 0.6 0.8 1.0 1.2
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Factory Drive Hi-Static Drive
2800 567 0.60 632 0.71 694 0.83 751 0.95 806 1.08 858 1.21 907 1.33
TABLE 15 - DSH096C – SUPPLY AIR BLOWER PERFORMANCE
SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
1
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Low Static Drive
3
Standard Factory Drive + 1.5HP Optional Hi-Static Drive + 2.0 HP
2400 458 0.31 543 0.42 619 0.53 690 0.64 752 0.75 812 0.87 878 1.04 935 1.21 985 1.40 1038 1.51 2800 503 0.44 580 0.57 650 0.69 715 0.83 776 0.97 831 1.11 885 1.27 942 1.45 998 1.65 1045 1.77 3200 542 0.60 613 0.74 678 0.88 739 1.02 796 1.18 847 1.33 903 1.49 960 1.66 1017 1.83 1072 2.01 3600 607 0.85 670 1.00 730 1.16 786 1.32 839 1.48 890 1.66 939 1.83 980 1.99 - - - - 4000 660 1.12 718 1.29 773 1.46 826 1.64 876 1.82 924 2.00 - - - - - - - -
NOTES: 1. Blower performance includes evaporator coil and 2-inch lters. 2. At higher evaporator airows and wet bulb conditions, condensate carry-over may occur. Decrease airow downward as necessary. 3. Field supplied low static drive.
