Johnson Controls DSH024C Series - TABLE 16 - DSH096 C - Condenser Fan Performance; TABLE 17 - DSH120 C - Supply Air Blower Performance; TABLE 18 - DSH120 C- Condenser Fan Performance

31
SECTION 1 – INSTALLATION
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
1
TABLE 16 - DSH096C – CONDENSER FAN PERFORMANCE
OUTDOOR
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
0.0 0.2 0.4 0.6 0.8 1.0 1.2
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Factory Drive +3 HP Optional Hi-Static Drive +3 HP
6100 516 1.53 572 1.79 623 2.06 672 2.33 718 2.60 762 2.88 805 3.16
TABLE 17 - DSH120C – SUPPLY AIR BLOWER PERFORMANCE
SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
1
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Factory Drive + 3 HP Optional Hi-Static Drive + 2.0 HP Field Supplied Drive
3
3200 486 0.60 548 0.73 604 0.87 657 1.01 706 1.15 753 1.30 800 1.48 847 1.68 885 1.89 923 2.07 3600 524 0.79 580 0.94 633 1.09 683 1.24 730 1.40 775 1.56 817 1.73 867 2.13 905 2.29 941 2.45 4000 568 1.05 619 1.21 668 1.37 715 1.54 759 1.71 802 1.88 843 2.06 882 2.24 920 2.43 962 2.76 4400 616 1.37 664 1.54 709 1.72 753 1.90 795 2.08 835 2.27 874 2.46 911 2.66 948 2.86 983 3.06 4800 660 1.72 704 1.91 747 2.10 788 2.29 827 2.49 865 2.69 902 2.90 938 3.11 - - - -
NOTES: 1. Blower performance includes evaporator coil and 2-inch lters. 2. At higher evaporator airows and wet bulb conditions, condensate carry-over may occur. Decrease airow downward as necessary. 3. For external static requirements outside of factory supplied drives consult factory for appropriate drive information. TABLE 18 - DSH120C– CONDENSER FAN PERFORMANCE
OUTDOOR
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Factory Drive +3 HP Optional Hi-Static Drive +5 HP
6400 691 1.98 747 2.24 800 2.52 850 2.80 898 3.08 945 3.36 990 3.66 1033 3.96 1075 4.26
