FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
SECTION 1 – INSTALLATION
Typical Service Clearances
LD27701
FIGURE 10 - 2–5 TON HORIZONTAL A/C UNIT SERVICE CLEARANCES
Front
Return Air
Supply Air
Evaporator Section
Condenser Section
Condenser
Intake
Condenser
Discharge
36 Inch Minimum Clearance
36 Inch Minimum Clearance
Evaporator
Fan Access
Condenser
Fan Access
4 Inch Minimum Clearance
(for Drain Trap)
