Johnson Controls DSH024C Series - TABLE 4 - Electrical Data - Standard Evaporator Motor; TABLE 5 - Electrical Data - Oversized Evaporator Motor

27
SECTION 1 – INSTALLATION
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
1
TABLE 4 - ELECTRICAL DATA – STANDARD EVAPORATOR MOTOR
MODEL # VOLTAGE
COMPRESSOR #1 COMPRESSOR #2
EVAP.
FAN
COND.
FAN
MCA
MAX
FUSE/
CCT. BKR.
AMP
QTY RLA LRA QTY RLA LRA HP FLA HP FLA
DSH024C2
208-
230/3/60
1 @ 7.7 55.4 0.5 1.6 0.5 1.6 12.83 20
DSH036C2
208-
230/3/60
1 @ 10.4 73 0.75 2.1 0.75 2.1 17.2 25
DSH036C4 460/3/60 1 @ 5.8 38 0.75 1 0.75 1 9.25 15
DSH036C5 575/3/60 1 @ 3.8 36.5 0.75 0.9 0.75 0.9 6.49 15
DSH048C2
208-
230/3/60
1 @ 13.8 83.1 0.75 2.1 1.5 4.4 23.75 35
DSH048C4 460/3/60 1 @ 6.2 41 0.75 1 1.5 2.2 10.95 15
DSH048C5 575/3/60 1 @ 4.9 33 0.75 0.9 1.5 1.8 8.8 15
DSH060C2
208-
230/3/60
1 @ 15.9 110 1 3.1 1.5 4.4 27.38 40
DSH060C4 460/3/60 1 @ 7.1 52 1 1.5 1.5 2.2 12.58 15
DSH060C5 575/3/60 1 @ 5.1 39.5 1 1.2 1.5 1.8 9.38 15
DSH096C2
208-
230/3/60
1 @ 14 83.1 1 @ 13.8 83.1 1.5 4.4 3 8.5 44.2 50
DSH096C4 460/3/60 1 @ 6.4 41 1 @ 6.2 41 1.5 2.2 3 4.2 20.6 25
DSH096C5 575/3/60 1 @ 4.6 33 1 @ 4.9 33 1.5 1.8 3 3.4 15.85 20
DSH120C2
208-
230/3/60
2 @ 16.2 110 3 8.5 3 8.5 53.45 60
DSH120C4 460/3/60 2 @ 7.6 52 3 4.2 3 4.2 25.5 30
DSH120C5 575/3/60 2 @ 5.3 38.9 3 3.4 3 3.4 18.73 20
TABLE 5 - ELECTRICAL DATA – OVERSIZED EVAPORATOR MOTOR
MODEL # VOLTAGE
COMPRESSOR #1 COMPRESSOR #2
EVAP.
FAN
COND.
FAN
MCA
MAX
FUSE/
CCT. BKR.
AMP
QTY RLA LRA QTY RLA LRA HP FLA HP FLA
DSH048C2
208-
230/3/60
1 @ 13.8 83.1 1 3.1 1.5 4.4 24.75 35
DSH048C4 460/3/60 1 @ 6.2 41 1 1.5 1.5 2.2 11.45 15
DSH048C5 575/3/60 1 @ 4.9 33 1 1.2 1.5 1.8 9.13 15
DSH060C2
208-
230/3/60
1 @ 15.9 110 1.5 4.4 1.5 4.4 28.68 40
DSH060C4 460/3/60 1 @ 7.1 52 1.5 2.2 1.5 2.2 13.28 20
DSH060C5 575/3/60 1 @ 5.1 39.5 1.5 1.8 1.5 1.8 9.98 15
DSH096C2
208-
230/3/60
1 @ 14 83.1 1 @ 13.8 83.1 2 5.8 3 8.5 45.6 50
DSH096C4 460/3/60 1 @ 6.4 41 1 @ 6.2 41 2 2.9 3 4.2 21.3 25
DSH096C5 575/3/60 1 @ 4.6 33 1 @ 4.9 33 2 2.3 3 3.4 16.35 20
