Johnson Controls DSH024C Series - Fan Performance; TABLE 6 - Electrical Data - Oversized Condenser Motor; TABLE 7 - DSH024 C - Supply Air Blower Performance; TABLE 8 - DSH024 C - Condenser Fan Performance

28
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
SECTION 1 – INSTALLATION
TABLE 6 - ELECTRICAL DATA – OVERSIZED CONDENSER MOTOR
MODEL # VOLTAGE
COMPRESSOR #1 COMPRESSOR #2
EVAP.
FAN
COND.
FAN
MCA
MAX
FUSE/
CCT. BKR.
AMP
QTY RLA LRA QTY RLA LRA HP FLA HP FLA
DSH120C2
208-
230/3/60
2 @ 16.2 110 3 8.5 5 14 58.95 70
DSH120C4 460/3/60 2 @ 7.6 52 3 4.2 5 6.6 27.9 35
DSH120C5 575/3/60 2 @ 5.3 38.9 3 3.4 5 5.3 20.63 25
FAN PERFORMANCE
TABLE 7 - DSH024C – SUPPLY AIR BLOWER PERFORMANCE
SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
1
0.0 0.1 0.2 0.3 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Low Static
Drive
3
Factory Drive + 0.5 HP Hi-Static Drive + 0.5 HP
600 318 0.03 426 0.04 520 0.06 604 0.08 679 0.10 810 0.14 923 0.19 - -
700 371 0.04 466 0.06 550 0.08 628 0.10 699 0.13 826 0.18 937 0.23 - -
800 423 0.06 508 0.08 585 0.10 656 0.13 723 0.15 844 0.20 - - - -
900 476 0.09 552 0.11 622 0.14 688 0.16 751 0.19 866 0.24 - - - -
1000 529 0.11 598 0.14 662 0.18 723 0.20 781 0.23 891 0.29 - - - -
NOTES:
1. Blower performance includes evaporator coil and 2-inch lters.
2. At higher evaporator airows and wet bulb conditions, condensate carry-over may occur. Decrease airow downward as necessary.
3. Field supplied low static drive.
TABLE 8 - DSH024C – CONDENSER FAN PERFORMANCE
OUTDOOR
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
0.0 0.2 0.4 0.6 0.8
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Factory Drive Hi-Static Drive
1600 461 0.16 573 0.23 675 0.31 767 0.39 849 0.48
TABLE 9 - DSH036C – SUPPLY AIR BLOWER PERFORMANCE
SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE – IWG
1
0.0 0.1 0.2 0.3 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Low Static
Drive
3
Factory Drive + 0.75 HP Hi-Static Drive + 0.75 HP
800 453 0.06 534 0.09 609 0.11 679 0.14 744 0.16 866 0.21 969 0.26 1065 0.33
1000 566 0.13 633 0.16 695 0.19 755 0.21 812 0.24 917 0.30 1016 0.38 - -
1200 680 0.23 735 0.26 789 0.29 840 0.33 890 0.36 983 0.43 1074 0.50 - -
1400 792 0.36 841 0.40 887 0.44 932 0.48 977 0.51 1061 0.59 - - - -
1600 906 0.54 948 0.58 990 0.63 1030 0.66 1069 0.71 - - - - - -
NOTES:
1. Blower performance includes evaporator coil and 2-inch lters.
2. At higher evaporator airows and wet bulb conditions, condensate carry-over may occur. Decrease airow downward as necessary.
3. Field supplied low static drive.
