4
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
NOMENCLATURE
MISCELLANEOUS
OPTIONS
A = None
D = Condensate
Overflow Switch
CONTROL OPTIONS
M = Simplicity Microprocessor Controls
S = Smart Equipment (SE) Microprocessor Controls
N = SE Microprocessor Controls with BACnet
®
REFRIGERANT CIRCUIT
OPTIONS
A = None
B = Hot Gas Bypass
PRODUCT CATEGORY
DS = Integral Air-Cooled
Packaged A/C, R-410A
PRODUCT IDENTIFIER
H = Horizontal, Ceiling Mounted
DESIGN SERIES
C = Current
VOLTAGE
2 = 208/230-60-3
4 = 460-60-3
5 = 575-60-3
NOMINAL CAPACITY
024 = 2 Ton
036 = 3 Ton
048 = 4 Ton
060 = 5 Ton
096 = 8 Ton
120 = 10 Ton
OUTDOOR FAN OPTIONS
1 = Standard
2 = High Static
3 = Standard with Low Ambient
Control VFD***
4 = High Static with Low Ambient
Control VFD***
INDOOR AIRSIDE OPTIONS
A = Standard AirsideCoil
C = Corrosion Protective Coating
D = Stainless Steel Drain Pan
F = Coated Coil with Stainless Steel Drain Pan
HEATING OPTIONS
0 = None
INDOOR FAN OPTIONS
1 = Standard*
2 = High Static*
3 = Standard with VFD (VAV)**
4 = High Static with VFD (VAV)**
5 = Standard with VFD Discrete Speeds**
6 = High Static with VFD Discrete Speeds**
*Evaporator and condenser motor VFD available only on 8 tons and up. Evaporator motor without VFD available only on 2, 3, 4, and 5 tons.
**Evaporator motor VFD standard on 8 tons and up.
***Condenser and motor VFD available only on 8 tons and up.
CABINET CONFIGURATION
P = Single Package (Standard)
S = Factory-Split (Charged R-410A)
N = Factory-Split (Nitrogen Charge Only)
OUTDOOR AIRSIDE OPTIONS
A = Standard Airside Coil
C = Corrosion Protective Coating
1, 2 3 4, 5, 6 7 8 9 10 11 12 13 14 15 16 17
DS H 120 C 2 S 1 P A A 1 A 0 A
