Johnson Controls Frick AcuAir Installation Operation & Maintenance









EXTERIOR SKIN
LINER
INTERNAL RECONNECT
.25-20 X .75 HEX BOLT
WITH .25 FLANGED LOCKNUT
(SUPPLIED BY JCI)
FIELD SEAL BEFORE
RECONNECTING SECTIONS
WITH POLYURETHANE CAULK
GASKET
INSTALLED
IN FIELD

POLYURETHANE
CAULK
NO GAPS
GASKET
SHIPPED LOOSE
AND INSTALLED
BY CONTRACTOR
GASKET
BASE RECONNECT FLANGE
.25 MINIMUM DIA
CONTINUOUS
POLYURETHANE
CAULKING - 2 PLACES
INTERNAL RECONNECT
