CAULK

CAULK ALONG SCREW

HOLE LOCATION

#10-16 SS TEK SCREW

W/EPDM WASHER (TYP)

CAULK

SHIPPING SPLIT COVER

Acceptable Polyurethane Caulking:

Manus-bond, Gray, P/N 013-02966-001 or

Sikaflex, Gray, P/N 013-03317-050 or

Sikaflex, Champagne P/N 013-03317-040

SHIPPING

SPLIT COVER

SHIPPING SPLIT

SHIPPING SPLIT COVER

DETAIL B

DETAIL A
























