System 450™ Series Control Module with Ethernet Communications Installation Instructions38
13 Sensor Failure
Mode of
Operation
Select from the drop-down menu how you want the relay output to respond when the
reference sensor or reference sensor wiring fails.
• If you choose Fail Off, the analog output generates the selected OSP (Output Signal
Strength at Setpoint) value to the controlled device.
• If you choose Fail On, the analog output generates the selected OEP (Output Signal
Strength at End Point) value to the controlled device.
In this example, Fail Off is selected. Therefore, if the reference sensor (Sn-1) or sensor
wiring fail, OUTA-2 provides the selected OSP (10%) to the controlled device until the
sensor failure is resolved.
14 (Output) Name Assign a 16-character or less web UI name for the analog output.
Note: You are not required to assign an output name. When you assign an output name,
the assigned name is displayed on the Overview page, the System Configuration
page, the Output Configuration pages and the Sensor Configuration page.
In this example, the assigned name is Cond Fan 2.
15 Ok
Button
Click Ok to save any changes you made on this web page and go to the System
Configuration page.
Note: If you leave a web page before clicking Ok, any changes made on the page are not
saved, and the page reverts to the previous values.
16 Cancel
Button
Click Cancel to cancel any changes you made on this web page, revert to the previous
values on the web page, and go to the System Configuration page.
Table 16: System 450 Web UI Analog Output Configuration Page, User Actions, Descriptions, and
References (Part 3 of 3)
Callout
Number
Identifier / Item
Name
User Actions, Descriptions, References
