System 450™ Series Control Module with Ethernet Communications Installation Instructions 43
12 Service Provider: Select the dynamic DNS provider. Options include None (dynamic DNS not used) or
DynDNS.com.
13 Host Name: Enter the host name used by your dynamic DNS provider. Leave this field blank if your
system does not use dynamic DNS.
14 User Name: Enter the user name for the account that is set up with your dynamic DNS provider. Leave
this field blank if your system does not use dynamic DNS.
15 Password: Enter the password for the account that is set up with your dynamic DNS provider. Leave
this field blank if your system does not use dynamic DNS.
16 External IP: This field automatically displays the C450 communications control module’s IP address as
seen from the Internet. This address can be used to troubleshoot Internet connectivity
issues between the control module and the dynamic DNS provider.
17 Ok
Button
Click Ok to save any changes you made on this web page.
Note: Changing the network configuration values initiates a reset of the System 450
communications module, which overwrites the direct connection values and the
new network configuration values take effect. Therefore the direct connection is
broken and you must use the new network settings to establish connection with the
control module or initiate a manual reset of the control module (in the control
modules local UI) to re-establish the direct connection values.
Note: If you leave a web page before clicking Ok, any changes made on the page are not
saved, and the page reverts to the previous values.
18 Cancel
Button
Click Cancel to cancel any changes you made on this web page, revert to the previous
values on the web page, and go to the System Configuration page.
Table 18: System 450 Web UI Relay Output Configuration Page, User Actions, Descriptions, and
References (Part 2 of 2)
Callout
Number
Identifier / Item
Name
User Actions, Descriptions, References
