Johnson Controls YORK OPTIVIEW CONTROL CENTER User Manual

JOHNSON CONTROLS
127
SECTION 4 - PRINTERS
FORM 160.10-O1
ISSUE DATE: 4/27/2018
4
Refrigerant Level Control
-----------------------------------------------------
Refrigerant Level Position = 35 %
Purge Control
-----------------------------------------------------
Total Purge Count = 127
Purge Window Time = 1 Min
Purge Window Count = 0
[Not displayed if Motor Type is not EM]
Electro-Mechanical Starter
-----------------------------------------------------
Motor Run = Off
% Full Load Amps = 0 %
[Not displayed if Motor Type is other than Mod B SSS]
Liquid-Cooled Solid State Starter
-----------------------------------------------------
Starter Model = 26L
Motor Run = Off
% Full Load Amps = 0 %
kW Hours = 20723 kWH
Input Power = 0 kW
Phase A Voltage = 422 V
Phase B Voltage = 449 V
Phase C Voltage = 449 V
Phase A Current = 0 A
Phase B Current = 0 A
Phase C Current = 0 A
Phase A Temperature = 109 ºF
Phase B Temperature = 109 ºF
Phase C Temperature = 110 ºF
[Not displayed if Motor Type is other than VSD]
Variable Speed Drive
-----------------------------------------------------
Motor Run = Off
% Full Load Amps = 0 %
Pre-Rotation Vanes Position = 0 %
Full Load Amps = 402 A
Precharge Relay Output = Off
Trigger SCR Output = Off
Water Pump Output = Off
kW Hours = 14528 kWH
Input Power = 0 kW
Output Frequency = 0 Hz
Output Voltage = 0 V
DC Bus Voltage = 600 V
DC Inverter Link Current = 0 A
Phase A Output Current = 0 A
Phase B Output Current = 0 A
Phase C Output Current = 0 A
Internal Ambient Temperature = 88 ºF
Converter Heatsink Temperature = 102 ºF
Phase A Heatsink Temperature [If TMIII VSD] = 93 ºF
Phase B Heatsink Temperature [If TMIII VSD] = 99 ºF
Phase C Heatsink Temperature [If TMIII VSD] = 97 ºF
Baseplate Temperature [If VyperDrive VSD] = 106 ºF
FIGURE 47 - SAMPLE PRINTOUT (HISTORY)
(CONT’D)
[Not displayed if Motor Type is not VSD, or Filter is not present]
Harmonic Filter Data
-----------------------------------------------------
Precharge Contactor = Off
Supply Contactor = Off
Operating Mode = Stopped
Phase Rotation = ABC
Total Supply kVA = 0 kVA
Total Power Factor = 0.00
DC Bus Voltage = 608 V
Heatsink Temperature [If TMIII VSD] = 102 ºF
Baseplate Temperature [If VyperDrive VSD] = 102 ºF
Voltage Peak N-L1 = 200 V
Voltage Peak N-L2 = 200 V
Voltage Peak N-L3 = 200 V
L1-L2 RMS Voltage = 215 V
L2-L3 RMS Voltage = 215 V
L3-L1 RMS Voltage = 215 V
L1 RMS Filter Current = 0 A
L2 RMS Filter Current = 0 A
L3 RMS Filter Current = 0 A
L1 RMS Supply Current = 0 A
L2 RMS Supply Current = 0 A
L3 RMS Supply Current = 0 A
L1 Voltage Total Harmonic Distortion = 1.5 %
L2 Voltage Total Harmonic Distortion = 1.2 %
L3 Voltage Total Harmonic Distortion = 1.1 %
L1 Supply Current Total Demand Distortion = 0.0 %
L2 Supply Current Total Demand Distortion = 0.0 %
L3 Supply Current Total Demand Distortion = 0.0 %
Motor Winding Temperature
-----------------------------------------------------
A1 = 193.3 ºF
B1 = 192.5
ºF
B2 = 193.1
ºF
Bearing Temperature
-----------------------------------------------------
Sensor 1 = 128.3
ºF
Sensor 2 = 129.5
ºF
FIGURE 47 - SAMPLE PRINTOUT (HISTORY)
(CONT’D)
