SECTION 4 - PRINTERS
NAMEPLATE INFORMATION
-----------------------------------------------
MOTOR CODE =
POWER (VOLTS) =
PHASES =
FREQUENCY ( HZ) =
LOOKED ROTOR AMPS =
FULL LOAD AMPS =
INRUSH AMPS =
SYSTEM INFORMATION
-----------------------------------------------
REFRIGERANT =
TONS =
GEAR CODE =
LIQUID TYPE =
BRINE PERCENT =
KILOWATTS INPUT =
VSD / SSS / EM =
FIGURE 46 -SAMPLE PRINTOUT (SALES ORDER)
(CONT’D)
YORK HISTORY 1
CHILLER ID 0
(c) 1997 – 2004 YORK INTERNATIONAL CORPORATION
Mon 22 Nov 2004 9:23:12 AM
SYSTEM READY TO START
LCSSS – LOGIC BOARD POWER SUPPLY
[Any warnings active at shutdown will be listed here]
Controls C.MLM.08.01
Run Time 0 Days 2 Hr 59 Min
Operating Hours = 25 Hr
Number Of Starts = 6
Control Source = Local
Evaporator
-----------------------------------------------------
Leaving Chilled Active Setpoint = 45.0 ºF
Chilled Liquid Pump = Stop
Chilled Liquid Flow Switch = Open
Leaving Chilled Liquid Temperature = 45.0 ºF
Return Chilled Liquid Temperature = 55.0 ºF
Evaporator Pressure = 75.0 Psig
Evaporator Saturation Temperature = 44.4 ºF
Evaporator Refrigerant Temperature = 44.5 ºF
[If Refrigerant Sensor enabled]
Small Temperature Difference = 0.5 ºF
Condenser
-----------------------------------------------------
Condenser Liquid Pump = Stop
Condenser Liquid Flow Switch = Open
Leaving Condenser Liquid Temperature = 95.0 ºF
Return Condenser Liquid Temperature = 85.0 ºF
Condenser Pressure = 200.0 Psig
Condenser Saturation Temperature = 101.4 ºF
Small Temperature Difference = 6.4 ºF
Drop Leg Refrigerant Temperature = 83.0 ºF
[If Drop Leg Sensor enabled]
Sub Cooling Temperature = 18.4 ºF
[If Drop Leg Sensor enabled]
Compressor
-----------------------------------------------------
Discharge Temperature = 120.0 ºF
Vent Line Solenoid = Off
Oil Sump
-----------------------------------------------------
Oil Pump Run Output = Off
Sump Oil Pressure (LOP) = 75.8 Psig
Pump Oil Pressure (HOP) = 76.6 Psig
Oil Pressure = 0.0 Psid
Oil Sump Temperature = 150.0 ºF
[Skip the following section if Hot Gas Bypass is not enabled]
Hot Gas
-----------------------------------------------------
Valve Position = 0 %
Pre-Rotation Vanes Position = 0 %
FIGURE 47 - SAMPLE PRINTOUT (HISTORY)
