Johnson Controls YORK OPTIVIEW CONTROL CENTER - FIGURE 48 - Sample Printout (Trend Data New or Existing Points); FIGURE 49 - Sample Printout (Custom Screen Report); FIGURE 50 - Sample Printout (Adaptive Capacity Control New Map Point Report); FIGURE 51 - Sample Printout (Adaptive Capacity Control Existing Map Points Report)

JOHNSON CONTROLS
128
FORM 160.10-O1
ISSUE DATE: 4/27/2018
SECTION 4 - PRINTERS
YORK TREND
CHILLER ID 163
© 1997 – 2004 YORK INTERNATIONAL CORPORATION
MON 09 OCT 2004 3:33:47 PM
DATA 1: LEAVING CHILLED LIQUID TEMPERATURE
DATA 2: RETURN CHILLED LIQUID TEMPERATURE
DATA 3: EVAPORATOR PRESSURE
DATA 4: LEAVING CONDENSER LIQUID TEMPERATURE
DATA 5: RETURN CONDENSER LIQUID TEMPERATURE
DATA 6: CONDENSER PRESSURE
TIME DATA 1 DATA 2 DATA 3 DATA 4 DATA 5
DATA 6
3:33:47 PM 45.5 °F 55.0 °F 39.0 PSIG 95.0 °F 85.0 °F
120.0 PSIG
3:33:48 PM 45.5 °F 55.0 °F 39.0 PSIG 95.0 °F 85.0 °F
120.0 PSIG
3:33:49 PM 45.5 °F 55.0 °F 39.0 PSIG 95.0 °F 85.0 °F
120.0 PSIG
3:33:50 PM 45.5 °F 55.0 °F 39.0 PSIG 95.0 °F 85.3 °F
120.1 PSIG
3:33:51 PM 45.5 °F 55.2 °F 39.1 PSIG 95.1 °F 85.4 °F
120.2 PSIG
FIGURE 48 - SAMPLE PRINTOUT (TREND DATA
NEW OR EXISTING POINTS)
YORK CUSTOM VIEW
CHILLER ID 0
(c) 1997 – 2004 YORK INTERNATIONAL CORPORATION
Mon 21 Jun 2004 1:28:25 PM
Leaving Chilled Liquid Temperature = 45.0 ºF
Return Chilled Liquid Temperature = 55.0 ºF
Leaving Condenser Liquid Temperature = 95.0 ºF
Return Condenser Liquid Temperature = 85.0 ºF
Evaporator Saturation Temperature = 41.0 ºF
Condenser Saturation Temperature = 78.5 ºF
Evaporator Pressure = 70.0 Psig
Condenser Pressure = 140.0 Psig
Oil Pressure = 45.0 Psid
% Full Load Amps = 50 %
FIGURE 49 - SAMPLE PRINTOUT (CUSTOM
SCREEN REPORT)
Log Time: Mon 12:45:39 PM 21 Jun 2004
D-P/P= 0.92; Prv Pos= 56; Freq= 39 Hz
Surge Type = Delta P/P Surge
Leaving Chilled Active Setpoint = 45.0 ºF
Leaving Chilled Liquid Temperature = 50.0 ºF
Return Chilled Liquid Temperature = 59.3 ºF
Leaving Condenser Liquid Temperature = 85.0 ºF
Return Condenser Liquid Temperature = 94.9 ºF
Evaporator Pressure = 7.2 Psig
Condenser Pressure = 13.8 Psig
% Full Load Amps = 94 %
FIGURE 50 - SAMPLE PRINTOUT (ADAPTIVE
CAPACITY CONTROL NEW MAP POINT REPORT)
D-P/P = 1.20; Prv Pos = 89; Freq = 58 Hz
D-P/P = 1.41; Prv Pos = 71; Freq = 46 Hz
D-P/P = 0.98; Prv Pos = 73; Freq = 52 Hz
D-P/P = 0.71; Prv Pos = 86; Freq = 39 Hz
D-P/P = 0.86; Prv Pos = 53; Freq = 48 Hz
D-P/P = 1.14; Prv Pos = 76; Freq = 51 Hz
D-P/P = 0.84; Prv Pos = 84; Freq = 37 Hz
D-P/P = 0.99; Prv Pos = 63; Freq = 46 Hz
FIGURE 51 - SAMPLE PRINTOUT (ADAPTIVE
CAPACITY CONTROL EXISTING MAP POINTS
REPORT)
