SECTION 2 - OPTIVIEW OPERATION
SLOT# DESCRIPTION
256 System: Chiller State
257 System: Coastdown Time Remaining
258 System: Prelube Time Remaining
259 System: Are Safety Shutdown Contacts Closed
260 System: Are Cycling Shutdown Contacts Closed
261 System: Are Anticipatory Alarm Contacts Closed
262 System: Operating Hours
264 System: Number of Starts
265 System: Is Stop Switch Closed
266 System: Is Start Switch Closed
267 System: Is Remote Ready to Start
280 External Contact: Is Remote Stop Closed
281 External Contact: Is Remote Start Closed
282 External Contact: Is MultiUnit Cycling Closed
283 External Contact: Is Remote Cycling Closed
284 External Contact: Is Auxiliary Safety Open
285 Jumper: Is Anti-Recycle Enabled
286 Jumper: Coastdown Operation
287 Jumper: Is Diagnostics Enabled
288 Jumper: Liquid Type
289 Jumper: Chilled Liquid Pump Operation
290 Jumper: Motor Type
291 Jumper: Power Failure Restart
292 Jumper: Pre-Run Operation
293 Jumper: Refrigerant Selection
294 Jumper: VSD Motor Supply Line Frequency
295 Jumper: Oil Pump Package
304 Options: Control Mode
305 Options: System Language
306 Options: Chiller ID Number
307 Options: Display Mode
336 Security: Log In Level
337 Security: Log In User ID
512 Sched: Is Schedule Enabled
1280 Pre-Rotation Vanes: Is Motor Switch Closed
1281 Pre-Rotation Vanes: Position
1282 Pre-Rotation Vanes: Are Vanes Opening
1283 Pre-Rotation Vanes: Are Vanes Closing
1284 Pre-Rotation Vanes: Are Vanes Holding
1285 Pre-Rotation Vanes: Control Mode
1296 Discharge: Temperature
1536 Oil: Differential Pressure
1537 Oil: Sump Temperature
SLOT# DESCRIPTION
1538 Oil Pump: Control Mode
1539 Oil Pump: Is Pump On
1540 Oil Pump: Manual Time Left
1541 Oil Heater: Is Control Enabled
1542 Oil Heater: Is Heater On
1543 Oil Return Solenoid: Is Solenoid On
1792 Leaving Chilled Liquid: Temperature
1793 Leaving Chilled Liquid: Temperature Differential
1794 Leaving Chilled Liquid: Is Flow Switch Closed
1795 Leaving Chilled Liquid: Is Pump On
1796 Leaving Chilled Liquid: Local Temperature
Setpoint
1797 Leaving Chilled Liquid: Remote Analog Tem-
perature Setpoint
1798 Leaving Chilled Liquid: Remote ISN Tempera-
ture Setpoint
1799 Leaving Chilled Liquid: Remote Modem Tem-
perature Setpoint
1800 Leaving Chilled Liquid: Selected Temperature
Setpoint
1801 Leaving Chilled Liquid: Control Sensitivity
1802 Leaving Chilled Liquid: Remote Temperature
Range
1803 Leaving Chilled Liquid: Restart Temperature
Offset
1804 Leaving Chilled Liquid: Restart Temperature
Setpoint
1805 Leaving Chilled Liquid: Shutdown Temperature
Offset
1806 Leaving Chilled Liquid: Shutdown Temperature
Setpoint
1807 Return Chilled Liquid: Temperature
1808 Evaporator: Pressure
1809 Evaporator: Saturation Temperature
1810 Evaporator: Small Temperature Difference
1811 Evaporator: Is Refrigerant Sensor Present
1812 Evaporator: Refrigerant Temperature
1813 Evaporator: Delta P / P
1814 Evaporator: Brine Low Cutout
1815 Smart Freeze Protection: Is Control Enabled
1816 Liquid Line Solenoid: Is Solenoid Installed
1817 Liquid Line Solenoid: Is Solenoid On
1818 Leaving Chilled Liquid: Remote Digital Tempera-
ture Setpoint
2048 Leaving Condenser Liquid: Temperature
TABLE 1 - MASTER SLOT NUMBERS LIST (FOR USE WITH TREND FEATURES)
