Johnson Controls YORK OPTIVIEW CONTROL CENTER User Manual

JOHNSON CONTROLS
99
SECTION 2 - OPTIVIEW OPERATION
FORM 160.10-O1
ISSUE DATE: 4/27/2018
2
SLOT# DESCRIPTION
2049 Leaving Condenser Liquid: Is Flow Switch
Closed
2050 Leaving Condenser Liquid: Is Pump On
2051 Return Condenser Liquid: Temperature
2052 Condenser: Pressure
2053 Condenser: Saturation Temperature
2054 Condenser: Small Temperature Difference
2057 Condenser: Is High Pressure Switch Closed
2058 Condenser: High Pressure Warning Threshold
2059 SubCooling: Temperature
2060 Drop Leg Refrigerant: Is Sensor Present
2061 Drop Leg Refrigerant: Temperature
2062 Vent Line Solenoid: Is Solenoid Installed
2063 Vent Line Solenoid: Is Solenoid On
2304 Motor: Starter Type
2305 Motor: Is Motor Starter On
2306 Motor: Current %FLA
2307 Motor: Is Motor Controller Switch Open
2308 Motor: Current Limit Local Setpoint
2309 Motor: Current Limit Remote Analog Setpoint
2310 Motor: Current Limit Remote ISN Setpoint
2311 Motor: Current Limit Remote Modem Setpoint
2312 Motor: Current Limit Selected Setpoint
2313 Motor: Pulldown Demand Time Remaining
2314 Motor: Pulldown Demand Limit Setpoint
2315 Motor: Pulldown Demand Time Setpoint
2316 Motor: Anti-Recycle Time Remaining
2317 Motor: Current Limit Remote Digital Setpoint
(Mod “B” Solid State Starters)
2570 LcSss: Input Power
2571 LcSss: Kilowatt Hours
2572 LcSss: Phase A Current
2573 LcSss: Phase B Current
2574 LcSss: Phase C Current
2575 LcSss: Phase A Voltage
2576 LcSss: Phase B Voltage
2577 LcSss: Phase C Voltage
2578 LcSss: Phase A Temperature
2579 LcSss: Phase B Temperature
2580 LcSss: Phase C Temperature
2581 LcSss: Starter Model
2582 LcSss: Full Load Amps
2583 LcSss: Voltage Range
2584 LcSss: Starting Current
2585 LcSss: Is Serial Communications OK
2586 LcSss: Panel to Sss Comm Errors
SLOT# DESCRIPTION
2587 LcSss: Sss to Panel Comm Errors
2816 VSD: Motor HP
2817 VSD: 100% Full Load Amps
2818 VSD: Input Power
2819 VSD: Kilowatt Hours
2820 VSD: DC Bus Voltage
2821 VSD: DC Inverter Link Current
2822 VSD: Output Frequency
2823 VSD: Output Voltage
2824 VSD: Phase A Current
2825 VSD: Phase B Current
2826 VSD: Phase C Current
2827 VSD: Is Precharge Relay On
2828 VSD: Is Trigger SCR On
2829 VSD: Is Water Pump On
2830 VSD: Control Mode
2831 VSD: Command Frequency
2832 VSD: Manual Frequency Increment
2833 VSD: Internal Ambient Temperature
2834 VSD: Converter Heatsink Temperature
2835 VSD: Phase A Heatsink Temperature
2836 VSD: Phase B Heatsink Temperature
2837 VSD: Phase C Heatsink Temperature
2838 VSD: Is Communications OK
2839 VSD: Panel to ACC Comms Error Count
2840 VSD: ACC to Panel Comms Error Count
2841 VSD: ACC to VSD Comms Error Count
2842 VSD: VSD to ACC Comms Error Count
2843 VSD: VSD to Filter Comms Error Count
2844 VSD: Filter to ACC Comms Error Count
2845 ACC: Delta P/P
2846 ACC: Stability Limit
2847 ACC: Surge Margin
2848 ACC: Manual Surge Command
2849 ACC: Surge Map Count
2850 ACC: Surge Type
2857 ACC: Surge Map Point Count
2858 ACC: Surge Map Delta P/P
2859 ACC: Surge Map Output Frequency
2860 ACC: Surge Map PRV Position
2861 Filter: Is Filter Installed
2862 Filter: Is Operation Inhibited
2863 Filter: Is Filter Running
2864 Filter: Is Precharge Contactor Closed
2865 Filter: Is Supply Contactor Closed
