JOHNSON CONTROLS
123
SECTION 4 - PRINTERS
FORM 160.10-O1
ISSUE DATE: 4/27/2018
4
Printer Setup
Access Level Required: OPERATOR
Using the COMMS Screen, the control center must be
configured to transmit data in the same format as the
Printer is configured to receive the data. The following
values must be entered.
• Baud Rate - Set as desired. Value selected must
agree with the installed printer’s conguration.
• Data Bits - 8
• Parity - None
• Stop Bits - 1
Automatic Data Logging
Access Level Required: OPERATOR
If automatic data logging is desired, a Status report can
be automatically printed at a specified interval begin-
ning at a specified time, using the Printer screen. The
interval is programmable over the range of 1 minute
to 1440 minutes in one minute increments. The first
print will occur at the programmed start time and oc-
cur at the programmed output interval thereafter. The
time remaining until the next print is displayed on the
Printer screen.
• Automatic Printer Logging - Enables and dis-
ables automatic data logging
• Log Start Time - Enter the time the rst print is
desired.
• Output Interval - Enter the desired interval be-
tween prints.
YORK UPDATE
CHILLER ID 0
(c) 1997 – 2004 YORK INTERNATIONAL CORPORATION
Mon 22 Nov 2004 8:50:45 AM
SYSTEM RUN
LEAVING CHILLED LIQUID CONTROL
[All warnings presently active will be listed here]
Controls C.MLM.08.01
Run Time 0 Days 2 Hr 59 Min
Operating Hours = 25 Hr
Number Of Starts = 6
Control Source = Local
Evaporator
-----------------------------------------------------
Leaving Chilled Active Setpoint = 45.0 ºF
Chilled Liquid Pump = Run
Chilled Liquid Flow Switch = Closed
Leaving Chilled Liquid Temperature = 45.0 ºF
Return Chilled Liquid Temperature = 55.0 ºF
Evaporator Pressure = 75.0 Psig
Evaporator Saturation Temperature = 44.4 ºF
Evaporator Refrigerant Temperature = 44.5 ºF
Small Temperature Difference = 0.5 ºF
Condenser
-----------------------------------------------------
Condenser Liquid Pump = Run
Condenser Liquid Flow Switch = Closed
Leaving Condenser Liquid Temperature = 95.0 ºF
Return Condenser Liquid Temperature = 85.0 ºF
Condenser Pressure = 200.0 Psig
Condenser Saturation Temperature = 101.4 ºF
Small Temperature Difference = 6.4 ºF
Drop Leg Refrigerant Temperature = 83.0 ºF
[If Drop Leg Sensor enabled]
Sub Cooling Temperature = 18.4 ºF
[If Drop Leg Sensor enabled]
Compressor
-----------------------------------------------------
Discharge Temperature = 120.0 ºF
Vent Line Solenoid = On
Oil Sump
-----------------------------------------------------
Auxiliary Oil Pump = Off
Sump Oil Pressure (LOP) = 75.8 Psig
Pump Oil Pressure (HOP) = 124.6 Psig
Oil Pressure = 47.8 Psid
Oil Sump Temperature = 150.0 ºF
Oil Heater = Off
[Skip the following section if Hot Gas Bypass is not enabled]
Hot Gas
-----------------------------------------------------
Valve Position = 15 %
Pre-Rotation Vanes Position = 75 %
FIGURE 44 - SAMPLE PRINTOUT (STATUS)
