SECTION 4 - PRINTERS
FORM 160.10-O1
ISSUE DATE: 4/27/2018
4
YORK SETPOINTS
CHILLER ID 0
(c) 1997 – 2004 YORK INTERNATIONAL CORPORATION
Mon 22 Nov 2004 8:48:27 AM
Software Versions
-----------------------------------------------------
Controls = C.MLM.08.01
BIOS = C.MLM.00.03
Kernel = 0.18
GUI = 0.33
SIO = 0.22
GPIC = 0.04
Ext I/O = 0110112091996
VSD [Not displayed if Motor Type is not VSD] = C.VSD.00.00
SSS [Not displayed if Motor Type is not Mod B SSS] = C.SSS.01.01
System Information
-----------------------------------------------------
System Language = English
Data Display Mode = English
Control Source = Local
Remote Analog Input Range = 0–10 Volts
Clock = Enabled
Jumper Settings
-----------------------------------------------------
Oil Pump Type = Standard
Coastdown = Standard
Chilled Liquid Pump Operation = Standard
Refrigerant Selection = R123
Anti-Recycle = Enabled
Power Failure Restart = Auto
Liquid Type = Water
Motor Type = Fixed Speed
Printer Setup
-----------------------------------------------------
Automatic Printer Logging = Disabled
Log Start Time = 12:00 am
Output Interval = 60 Min
Printer Type = Okidata
Baud = 9600 Baud
Data Bits = 8 Bits
Parity = None
Stop Bits = 1 Bit
COM 2 Setup
-----------------------------------------------------
Baud = 19200 Baud
Data Bits = 8 Bits
Parity = Odd
Stop Bits = 1 Bit
Evaporator
-----------------------------------------------------
Leaving Chilled Local Setpoint = 45.0 ºF
Leaving Chilled ISN Setpoint = 45.0 ºF
Leaving Chilled Modem Setpoint = 45.0 ºF
Leaving Chilled Analog Setpoint = 45.0 ºF
Leaving Chilled Digital Setpoint = 45.0 ºF
Remote Range = 10.0 ºF
Sensitivity = 100%
FIGURE 52 - SAMPLE PRINTOUT (SETPOINTS)
Restart Offset = 0.0 ºF
Restart Setpoint = 45.0 ºF
Shutdown Offset = 4.0 ºF
Shutdown Setpoint = 41.0 ºF
Brine Low Evaporator Cutout = 12.5 Psig
Smart Freeze = Off
Refrigerant = Enabled
Condenser
-----------------------------------------------------
High Pressure Warning Threshold = 28.8 Psig
Drop Leg = Enabled
Oil Sump
-----------------------------------------------------
Manual Pump = Disabled
Low Pressure Limit = 15.0 PSID
Prelube Time = 30 Sec
Coastdown Time = 150 Sec
Purge Control
-----------------------------------------------------
High Efciency = Off
Maximum Purge / Hour = 20
[Following section not displayed if Hot Gas Bypass is not enabled]
Hot Gas
-----------------------------------------------------
Hot Gas = Enabled
Hold Period = 30 Min
Close Percentage = 5 %
[Following section not displayed if Level Control is not enabled]
Refrigerant Level Control
-----------------------------------------------------
Level Control = On
Setpoint = 50 %
Period = 3.5 Sec
Proportion Limit Open = 15 %
Proportion Limit Close = 45 %
Rate Limit Open = 10 %
Rate Limit Close = 10 %
[Not displayed if Motor Type is not EM]
Electro-Mechanical Starter
-----------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
FIGURE 52 - SAMPLE PRINTOUT (SETPOINTS)
(CONT’D)
