Johnson Controls YORK YK Style G OPTIVIEW - FIGURE 4 - Refrigerant Flow-Thru Chiller (Flooded Evaporator)

FORM 160.75-O1 (211)
JOHNSON CONTROLS
10
SECTION 1 - DESCRIPTION OF SYSTEM AND FUNDAMENTALS OF OPERATION
Refrigerant Flow-Thru Chiller
(Flooded Evaporator)
FIGURE 4 - REFRIGERANT FLOW-THRU CHILLER (FLOODED EVAPORATOR)
Rev. 2 (12-09-2010)
Dan Sowers
dan.sowers-ext@jci.com
(717) 771-7535
YK Mod G
Refrigerant Flow-Thru Cross-Secon Diagram
(Flooded Evaporator)
COMPRESSOR
EVAPORATOR
DISCHARGE
PRE-ROTATION
VANES
MESH ELIMINATORS or
SUCTION BAFFLE
SUB-COOLER
LIQUID LEVEL
CONDENSER
SUCTION
LIQUID LEVEL
VALVE
LIQUID LEVEL
OPTIONAL
ISOLATION
VALVE
OPTIONAL
ISOLATION
VALVE
HOT GAS
BYPASS VALVE
OPTIONAL HOT GAS
BYPASS LINE
LD00924B
