Johnson Controls YORK YK Style G OPTIVIEW - FIGURE 3 - Refrigerant Flow-Thru Chiller (Falling Film Evaporator)

SECTION 1 - DESCRIPTION OF SYSTEM AND FUNDAMENTALS OF OPERATION
JOHNSON CONTROLS
9
FORM 160.75-O1 (211)
1
Refrigerant Flow-Thru Chiller
(Falling Film Evaporator)
FIGURE 3 - REFRIGERANT FLOW-THRU CHILLER (FALLING FILM EVAPORATOR)
Rev. 2 (10-11-2010)
Dan Sowers
dan.sowers-ext@jci.com
(717) 771-7535
YK Mod G
Refrigerant Flow-Thru Cross-Secon Diagram
(Falling-Film Evaporator)
COMPRESSOR
EVAPORATOR
DISCHARGE
PRE-ROTATION
VANES
SUCTION
BAFFLE
SUB-COOLER
LIQUID LEVEL
CONDENSER
LIQUID LEVEL
VALVE
HOT GAS
BYPASS VALVE
LIQUID LEVEL
SUCTION
OPTIONAL
ISOLATION
VALVE
OPTIONAL
ISOLATION
VALVE
OPTIONAL HOT GAS
BYPASS LINE
LD00924A
