Johnson Controls YORK YK Style G OPTIVIEW - FIGURE 9 - System Components Front View

FORM 160.75-O1 (211)
JOHNSON CONTROLS
18
SECTION 3 - SYSTEM COMPONENTS DESCRIPTION
FRONT VIEW
FIGURE 9 - SYSTEM COMPONENTS FRONT VIEW
VARIABLE
SPEED
DRIVE
EVAPORATOR
COMPRESSOR
SUCTION
RELIEF
VALVES
SIGHT
GLASS
VARIABLE SPEED
OIL PUMP
CONTROL BOX
OPTIVIEW CONTROL
CENTER
LD15222
